RCTIMER 20A BLHeli OPTO Mini Brushless ESC Speed Controller For Quadcopter Multicopter
Description:
Voltage: 6-16.8V (2-4S Lipo)
Output current: 20A
BEC: No
Signal frequency: 20-500Hz
Output PWM frequency: 18KHz
Firmware:BLHeli
Weight: 2g(without wire) 7.6g(with wire)
Dimension: 23x12x4.5mm
Features:
oneshot and damped light both enabled!
Specially for Multi-copter, throttle respond fast;
Suit for throttle, which can compatible well with motor;
Throttle signal is twisted pair cable, reduce the crosstalk while the signal transfer by the copper wire and flight more stable;
Use new process ultra-low resistance MOSFET with miniaturization, and all flashes are N MOS with high withstanding current;
Minaturization design, Mini20A with high performance capacitor fliter on the board, weight reduce to 2g, also already thicken the PCB copper specially and low heat for small aircraft.
Package Included:
1 x RCTIMER 20A Brushless ESC
