RC250 Frame Kit Combo w/MX1804 12A ESC 5030 Propeller CC3D FC
Description:
Mini 250 FPV Quadcopter Frame Specifications:
Materials: 3k Weave Carbon Fiber
Fasteners: Stainless Steel + Nylon 6/6
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor; about 1/2 the size of a regular quadcopter
Maximum Propeller: 5"
Motor Mount: M2 12mm - 16mm (Tiger MN1806 2300kv, RCX 1804 2400kv), M3 19mm (Tiger MT2206 2000kv, Sunnysky
X2204 2300kv)
Flight Controller Mount: 30.5mm x 30.5mm
Board Camera Mount: 32mm x 32mm
Motor Specification:
Brand Name: MARSPOWER
Brand Name: MARSPOWER
Model: MX1804
Motor KV value: 2480KV
Motor Diameter: 22mm
Motor Length (without shaft):22.8mm
Stator Diameter: 18mm
Stator Length: 4mm
Shaft: 3.17mm
Batteries: 2-3Cells
No Load Current: 0.3A
Top Mounting Holes: None
Bottom Mounting Holes:4*(12*12)mm
Weight: 18g
Package weight: 28 g
Design: CW,CCW
12A ESC Specifications:
Input Voltage: 2-3S LIPO
Working Current: 12A
BEC: 5V / 1A
Dimensions: 38 x 20 x 6 mm
Weight: 30 g
Package weight: 40G
CC3D Flight Controller Introduction:
Item name: CC3D Atom/Mini CC3D/CC3D EVO
Size (board only): 30mm x 17mm
Size (in case): 22 x 38 x 12mm WxLxH
Features:
With stable performance, it is practical and durable
Offering you high compatibility, reliability and stability
Driving and controlling motor to complete all kinds of instructions
Suitable for 250 Mini four axis and F330 aircraft,etc
It is very popular in retail market
Great Outrunner Brushless Motor
Package Included:
1 x Mini 250 FPV Quadcopter Frame (Not assembled)
1 x ESC Connection Board
4 x Motor
4 x 12A Simonk ESC
2 x 5030 Propeller Pair
1 x CC3D Flight Control Board Set
