RadioLink R7EH-S 2.4G 7CH Receiver For T6EAP T6EHP T7F Transmitter
Description:
Brand Name: Radiolink
Item Name: R7EH-S receiver
Channel: 7CH
Max input voltage: 6V
Size: 50*24*15mm
Weigh: 11.4g
Current: 19-25mA (voltage 5V)
Signal output: S-BUS, PPM and PWM
PWM signal mode: Green LED, output 8 channels PWM signal.
SBUS/PPM signal mode: Both red and green LED on, CH1 output S-BUS signal, CH2 output PPM signal, CH3 to CH8 output PWM signal at the same time, FHSS, nice anti-interference.
Features:
R7EH-S, 2.4G 7 channels receiver, FHSS, use for Radiolink TX T4EU, T4EU-6, T6EHP-E, S-BUS, PPM and PWM signal is possible working at the same time.
How to match code with transmitter:
First, turn on the transmitter, then give power to receiver, there is a black button near the antenna, use a thin stick press the button two seconds and release, receiver light start blinking, after about 8 times blinking, match code success when receiver signal LED on!
S-BUS, PPM and PPM signal change:
Short press the ID SET switch two times within 1 second, the signal is changed from normal PWM to S-BUS or PPM. The green LED indicates the normal PWM and red&green LED indicates S-BUS or PPM signal.
Fail safe:
Receiver will output signal:throttle zero, other channels keep the last signal from transmitter when receiver can't receive signal from transmitter within 1 second.
Package included:
1x RadioLink R7EH-S 2.4G 7CH Receiver
