Racerstar RS20Ax4 20A 4 in 1 Blheli_S Opto ESC 2-4S Support Oneshot42 Multishot for FPV Racer
Specification:
Brand Name: Racerstar
Item Name: 20A 4 in 1 Blheli_S Opto 2-4S ESC
Model: RS20Ax4
Input Voltage: 2-4S
Con.Current:20A
Peak Current(10s):25A
BEC:NO
Programming :YES
Installing Distance: 30mm
Weight:19g
Size(PCB):36x36mm
Features:
-with Blheli_S firmware
-4 in 1 ESC, more easier to install
-with 24MHz BB1 Clip
-Support oneshot42 multishot
-Small size and light weight
How to Flash the ESC? Please click here
-Rev 16.2 Fixed bug that prevented temperature protection
-Improved robustness to very high input signal rates
-Beeps can be turned off by programming beep strength to 1
-Throttle cal diffirence is checked to be above required minimum before storing
-Throttle cal max is not stored untill successful min throttle cal.
Package Included:
1x RS20Ax4 20A 4 in 1 ESC
1x Screws bag
