Description:
Brand: Racerstar
Item: 2430 Motor
Waterproof Level: Splash-proof
Motor Features:
- 4 pole 12 slot hi-torque motor design
- CNC machined 6061 T6 billet aluminum heatsink can
- High purity copper windings maximizes efficiency
- High RPM ABEC 5 oversized bearings
- Universal fit, fits all 1/16, 1/18, 1/20 brushless cars; multi-mounting system for M2.5 screws
- Precision balanced rotor, smoothness for best reliability and maxium RPM
- Stator- super thin (0.35mm) laminations
- Removalbe/replaceable rotor
- Precision engineered for maxium energy coversion
Motor Specification:
Product Watts Max Voltage Max Amps Rotor Poles IO Resistance KV
(RPM/Volt) Max RPM Length Diameters Weight
(g) Shaft
(mm) Length of Extend Shaft Connector 2430 200 8.4V 24A 4 2.3A 0.007 7200 60000 30mm 24mm 58 ï¿ 2 12mm 3.5mm gold 2430 200 10.8V 18A 4 1.9A 0.013 5800 60000 30mm 24mm 58 ï¿ 2 12mm 3.5mm gold 2430 200 7.2V 28A 4 3.6A 0.004 8200 60000 30mm 24mm 68 ï¿ 2 12mm 3.5mm
gold
Note:
Racerstar 2430 motor usually works with 25A ESC.
For more information, .
Package Included:
1 x Motor
