QX-Motor 64mm 12 Blades Ducted Fan With 3500KV 3-4S QF2822 Brushless Motor
Description:
Brand Name: QX-Motor
Item Name: Ducted fan with brushless motor set
Ducted Fan: 64mm 12 blades
Motor: QF2822 brushless motor
Recommended Battery: 3-4s Lipo (not included)
Recommended ESC: 60A,80A (not included)
Specifications of Motor:
KV 3500 Idle Current @10.0V 3.5A Configuration 9N6P No.of Cells(Lipo) 3-4S Stator Diameter 22mm Max Continuons Current(A)/60s 55A Stator Length 22mm Max Continuous Power(W)/60s 850W Shaft Diameter Φ4mm Max Efficiency >70% Motor Dimension 28x61mm Internal Resistance 0.033oh,s Weight 90g Recom. ESC 65A
Tested With 80A ESC:
Prop Volts(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) 64FAN/12-Blade 14.8V 52.0 769.6 1250 44.09 1.62 0.06
Packege Included:
1x QX-motor 64mm 12 blades ducted fan w/QF2822 3500KV motor
