250mm Mini FPV Quadcopter Frame Kit<br />
<br />
The Mini Quad is a low weight Mini Sport FPV Quadcopter frame.It was designed to make use of standard sized electronic equipment commonly used in RC. This allows the quadcopter to compete with larger quadcopters, while being smaller and agile.<br />
<br />
Description:<br />
Item Name: QAV250<br />
Materials: 3k Weave Carbon Fiber<br />
Fasteners: Stainless Steel & Red Metal 8/8<br />
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor; about 1/2 the size of a regular quadcopter<br />
Maximum Propeller: 6" (Suggest 5030 propeller)<br />
Motor Mount: M2 12mm - 16mm (Tiger MN1806 2300kv, RCX 1804 2400kv), M3 19mm (Tiger MT2206 2000kv, Sunnysky X2204 2300kv)<br />
Flight Controller Mount: 30.5mm x 30.5mm<br />
Board Camera Mount: 32mm x 32mm<br />
<br />
Features:<br />
Carbon Fiber Materials<br />
Light weight Mini Sport FPV Quadcopter frame<br />
Designed to make use of standard sized electronic equipment commonly used in RC<br />
<br />
Recommended Configuration(Not included):<br />
4 x Motors EMAX MT1806 KV2280 <br />
4 x 12A SimonK ESC <br />
4 x Propellers (size: 5x3 ) <br />
4 x Gemfan 5x3 3-Leaf Propellers <br />
1 x CC3D Flight controller <br />
1 x 700TVL 2.8mm camera <br />
1 x 11.1V 1500mAh battery <br />
Video Transmitter: ImmersionRC 600mw Video Transmitter<br />
Antenna: ImmersionRC SpiroNet V2 (SMA)<br />
QAV250 motor ESC propeller Set <br />
<br />
Note: This product only included frame kit,not included other accessories.<br />
<br />
Package included:<br />
1 x QAV 250 Frame Kit<br />
