250mm Mini FPV Quadcopter Frame Kit
The Mini Quad is a low weight Mini Sport FPV Quadcopter frame.It was designed to make use of standard sized electronic equipment commonly used in RC. This allows the quadcopter to compete with larger quadcopters, while being smaller and agile.
Description:
Item Name: QAV250
Materials: Glass Fiber
Fasteners: Stainless Steel & Red Metal 8/8
Weight: 140g (not included screw),30g ( Screws)
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor; about 1/2 the size of a regular quadcopter
Maximum Propeller: 5"
Motor Mount: M2 12mm - 16mm (Tiger MN1806 2300kv, RCX 1804 2400kv), M3 19mm (Tiger MT2206 2000kv, Sunnysky X2204 2300kv)
Flight Controller Mount: 30.5mm x 30.5mm
Board Camera Mount: 32mm x 32mm
Features:
Glass Fiber Materials
Light weight Mini Sport FPV Quadcopter frame
Designed to make use of standard sized electronic equipment commonly used in RC
This allows the quadcopter to compete with larger quadcopters, while being smaller and agile
This product requires a good knowledge of RC systems and is not recommended for beginners
Working on Mini Quadcopters requires a lot of soldering, wire shortening and creation of power distribution systems
Recommended Configuration(Not included):
4 x Motors EMAX MT1806 KV2280
4 x 12A SimonK ESC
4 x Propellers (size: 5x3 )
4 x Gemfan 5030 3-Leaf propellers
1 x CC3D Flight controller
1 x 700TVL 2.8mm camera
1 x 11.1V 1500mAh battery
Video Transmitter: ImmersionRC 600mw Video Transmitter
Antenna: ImmersionRC SpiroNet V2 (SMA)
QAV250 motor ESC propeller Set
Note: This product only included frame kit,not included other accessories.
Package included:
1 x QAV 250 Glass Fiber Frame Kit
