PX4 Pixhawk Lite V2.4.6 32bit Open Source Flight Controller Combo with NEO-M8N GPS PPM PM
Description:
Pixhawk Lite:
Easy to use and compatible V2.4.5 or V2.4.6
Removes some ports which unnecessary,like SPKT/DSM,BUZZER,CAN,SPI and USB pin port
Combins ADC 3.3V and ADC 6.6V ports
The mounting holes appear to be 30x30mm spaced
Size: 43x42mm
Note: Standard APM and Pixhawk power module can be directly used in this pixhawk lite case(V2)version.
Ublox Neo-M8N GPS:
Quick satellite searching, only need 10s to find 6 satellite in open space
Built-in compass, refresh rate up to 10GHz
Support GPS+BD+SBAS, or GPS+GLONASS+SBAS
OSD:
ATMEGA328P Microcontroller
MAX7456-EUI monochrome on-screen display
5V/500mA DC/DC regulator for MAX7456-EUI
Operating voltage: 5V(FTDI connector) and 12V(Video I/O connector)
Supported NTSC & PAL
FTDI connector
Full MAVLink protocol support
Graphical configurator tool
Dimension: 19mmx39mm(no include 0.1” pith 90°connector)
Weight: 5g/6g(include cable)
Package included:
1 x PX4 Pixhawk Lite V2.4.6 32Bits Open Source Flight Controller
1 x Safety button
1 x PPM module
1 x Pixhawk-I2C Splitter Expand Module
1 x NEO-M8N GPS
1 x Power Module(PM)
1 x OSD Module
1 x USB cable
1 x 3DR radio Data Transmission Module(433Mhz/915Mhz optional)
