PPM Decoder Board Module For Pixhawk Flight Controller.
Description:
Item Name:PPM Decoder Board Module
Size:35mm*25mm*6m
Product Weight: 9g
Input Voltage:5V
Note:
1. PPM decoder by P1 to P8 pin connected to the receiver, the receiver input signal of 8 road, and through the ATMEGA328 IC to collect all the way into the signal output to the flight control by RD motherboard
2. PPM decoder access voltage, the plate on the LED lights flash, no signal input, when the LED slow flash,that input signal.
Package Included:
1 X PPM decoder module
1 X PPM input cable for 10-position single line
1 X PPM output cable for 4-position single line
