Power HD have introduced their budget-friendly new waterproof HV servo LW-25MG. It makes use of a CNC-machined all-alloy case for improved durability, newly wiring outlet structure for enhanced waterproof function, having 36CM wire to compatible with Traxxas TRX-4 wiring.
It is usable with 6.0V to 8.4V input, offer a torque of up to 25kg-cm at a speed of down to 0.14s.
Description:
Brand: Power HD
Item: LW25MG
Product: Digital Servo
Torque(6.0V): 23.0 kg-cm (319.4 oz/in)
Torque(7.4V): 25.0 kg-cm (347.2 oz/in)
Speed: 0.16 sec (6.0V) â 0.14 sec (7.4V)
Operating Voltage: 6.0 ~ 8.4 DC Volts
Weight: 72 g (2.54 oz)
Bearing Type: Ball Bearing x 2
Motor Type: DC Motor
Gear Type:ãCopper & Aluminum
Operating Temperature: -20â~60â
Working Frequence: 1520μs / 333hz
Size: 40.7 x 20.5 x 38.6 mm ( 1.60 x 0.81 x 1.52 in)
Package:
1* Power HD LW25MG Servo
