Pixhawk PX4 2.4.6 Flight Controller NEO-M8N GPS Radio Telemetry PPM OSD 3DR 915Mhz
Description:
PIXHAWK intergrated the newest 32 bit chip technology and sensor technology, get rid
of the dilemma of having only 8 bit CPU of APM, and CPU occupancy being too high
Features:
- with external LED -Dual Size full angle LED
- Advanced 32 bit ARM CortexM4 high performance processer, can operate NuttX RTOX
real time operation system
- 14 PWM/ Servo Output
- Bus interface(UART,I2C,SPI,CAN)
- Intergrated back up power and lose efficacy controller, main controller lose
efficacy can safely alter to back up control
- Providing automatic and manual mode
- Providing redundant power supply input and failover
- Multicolor LED light
- Providing multi sound buzzer interface
- Micro SD records flying data
Hardware parameters
Processor:
- 32 bit 2M flash memory STM32F427 Cortex M4, with hardware floating point
processing unit
- Main frequency: 168MHZ,256K RAM
- 32 bit STM32F103 back up processor
Sensor:
- L3GD20 3 axis digital 16 bit gyroscope
- LSM303D 3 axis 14 acceleration/magnetometer
- MPU6000 6 axis acceleration/magnetometer
- MS5611 high precision barometer
Interface:
- 5 UART, one compatible high voltage, two have hardware flow control
- Two CAN
- Spektrum DSM/ DSM2/ DSM-X satellite receiver compatible input
- Futaba SBUS compatible input and output
- PPM signal input
- RSSI(PWM or voltage) output
- I2C
- SPI
- 3.3 and 6.6VADC input
- External MICRO USB interface
Package Included:
- 1 x Pixhawk px4 2.4.6 32 bit ARM Flight Controller with shell
- 1 x Buzzer module
- 1 x Safety button
- 1 x Anti-vibration set for pix board
- 1 x PPM module
- 1 x External LED light board(not included)
- 1 x NEO-M8N GPS
- 1 x Power Module T-plug type
- 1 x Pixhawk-I2C Splitter Expand board
- 1 x 3DR radio 915Mhz Data Transmission Module
- 1 x mini USB cable
- 1 x minimosd
