Specification:
Modulate Wideband FM Modulate Video Format NTSC Pixel 768(H)X494(V),600TVL FOV 120 degree Lens
4: 32.8mm lens,
M7 thread, the lens can not be changed
Charateristics
Value
Units
Min.
Typ.
Max.
1
Output powetr
25
100
200
mW
2
VCC
+3
+3.3
+5
V
3
Supply current@+5v@ 200mw
400
420
440
mA
4
Video band width
0
- -
8.0
MHz
5
Video input level
0.8
1.0
1.2
Vp-p
6
Dimensions(LXWXH)
19.5x18.3x16
mm
7
Weight
≤5(including antenna)
g
M7 thread, the lens can not be changed
Features:
1. Output power is stable, transmission distance: ≥ 0.5km @ 25mW, ≥ 0.8km @ 100mW, ≥ 1km @ 200mW
2. Transmit power 3 gear switchable: 25mW / 100mW / 200mW
3. Camera with wide dynamic range, low light characteristics, bright and dark environment, the image processing quickly
4. Output 48 frequency points, and have E group, F group of 16 competing frequency at the same time using each other without interference
5. Frequency lock fast, boot does not interfere with companions
6. Self-test function comes with output power
7. Wide input voltage range, low power consumption: + 3.3V ~ + 5V, + 5V / 400mA @ 200mW;
8. Small size: 19.5mm × 18.3mm × 16mm (including lens size)
9. Light weight: ≤ 5g (including antenna)
Package included:
1 x PandaRC CAM-A600 FPV Transmitter Camera Combo
Package included:
1 x PandaRC CAM-A600 FPV Transmitter Camera Combo
