Description(user manual):
This is a flight control with STM32F722 and ICM20689 mainstream FPV small frame. The input voltage is 2S-6S. It has BEC-5V output 3A current.
It has a large current PDB interface and integrates 600MW power adjustable OSD. The parameter-adjustable picture transmission supports the
mainstream PPM, SBUS, IBUS, DSM2/DSMX and other receivers on the market. There is LED_STRIP interface, active buzzer interface. Integrated
OSD function, support DSHOT ESC.
Specification:
Item name: NTXF7 F7 Flight Controller
CPU: STM32F722RET6
Sensor: ICM20689
Barometer: BMP280
With 600MW adjustable power, OSD adjustable parameter map
Four-way high current PDB distribution board
Receiver: PPM, SBUS, IBUS, DSM2/DSMX.
LED_STRIP interface
Active buzzer interface
No black box
Built-in ammeter, current detection
Camera interface
Comes with BEC 5V 3A
Screw hole spacing: 30.5*30.5MM
Diameter: 4.4MM
Dimensions: 41*51MM (including the pad length of the bonding wire)
Weight: 13.5g
Features:
1. Using F7 firmware
2. The main control is STM32F722 with a refresh rate of up to 32K.
3. PCB enhances copper thickness, enhances current stability and fast heat dissipation
4. BEC is 5V3A output
5. Exposed pads for easy soldering and the ability to discard conventional splitter boards.
6. Compatible with all ESCs in the market
7. Flight Control Integrated OSD does not need to independently write firmware, support BF ground station to adjust OSD
8. Integrated galvanometer, real-time monitoring of data such as current consumption
9. You can use the remote control to make OSD adjustment data such as flight control PID (TX5 configuration OSD adjustment, IRC Tramp)
10. Open ports can be adjusted from OSD, such as power, frequency band, and frequency.
11. F7 flight control adopts four independent damping balls, which can filter and offset the vibration of the motor, which makes the flight experience better.
Receiver connection configuration: PPM, SBUS, IBUS, DSM2, DSMX---RX2 port
Package included:
1x NTXF7 F7 Flight Controller
1x XT60 inner needle
4x Shock Absorbing Ball
1x IPEX-SMA (inner needle)
4x Nylon column M3*6
4x Nylon screw M3*8
1x Electrolytic capacitor 1000UF/25V
1x 14AWG red line 100MM
1x 14AWG black line 100MM
1x Heat Shrink Tubing Red 15MM
1x Heat Shrink Tubing Black 15MM
