New Version Feiyu Tech FY MiNi3D 3 Axis Gimbal For GoPro4 GoPro3+ GoPro3 Sport Camera - 134.19 €

New Version Feiyu Tech FY MiNi3D 3 Axis Gimbal For GoPro4 GoPro3+ GoPro3 Sport Camera
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


New Version Feiyu Tech FY MiNi3D 3-Axis Brushless Gimbal For Gopro4 Gopro3+ Gopro3 Sport Camera







Description:
Minimum Standard Maximum Remark Working Voltage 7.0V 8.4V 17.0V Static attitude tracking accuracy 0.01 0.02 0.05 Gimbal static mode Motion attitude tracking accuracy 0.1 0.2 0.5 Motor overload less than 2G Motor overload protection current 800mah Pitch angle -150°(down) 0°(horizontal) +150°(up) Roll angle -45° 0°(horizontal) +45° Heading angle -120° +135° Pitch following rate 2°/sec 25°/sec Heading following rate 3°/sec 75°/sec Weight : 149g (Not included camera)
Features:
Three working mode: Heading Follow Mode/Heading and Pitch Follow Mode/Heading Lock Mode
Suit for Gopro4 Gopro3+ Gopro3 Sport Camera or cameras with similar size
Magnetic encoder can accurately perceive attitude in motor sports
Leading motor-drive solutions, smooth and stable sine wave output
Single attitude sensor intervention,accurately sense three motor position relationship
Seamless exchange-axis technology
Motor Built-in limit,ensure the orderly rotation to prevent stranded wire
CNC, anodic oxidation frame processing techniques
Gimbal initialization method:
The gimbal is placed,remain stationary,then turn on the power,wait gimal operation,after operating,you can pick up the gimbal to work.

When connect to RC receiver it can switch in 3 working modes, also can control the heading and pitch via the RC receiver.

Heading Follow Mode:
Camera Pitch and Roll angles remain constant, heading follows
the nose position,pitch can be control by RC .

Heading And Pitch Follow Mode:
Camera Roll angle remains constant. Heading follow
the nose position and Pitch follow the elevation of the aircreft.

Heading Lock Mode:
Heading, Pitch and Roll are all locked to point at one position.
Heading and pitch can be control by RC .

The gimbal needs to be initialized when the following situations occur:
-After starting,there is a small angle deviation between pitch angle and the horizontal.
-There is a small angle deviation between roll angle and the horizontal.
-Keeping heading stationary,heading angle has frequent small angle correction.

Products Caution:
1.Please after installing the Gopro camera ,open the power.
2.Be sure to use the USB conversion head when you connect it to the computer for upgrading firmware,
3.First time using,turn on the power of gimbal,remain gimbal stationary,wait that gimbal initialization is completed,automatically back the gimbal to the horizontal position,it can be used normally,you needn't setting and adjusting parameters.

Note:Don't use the gimbal over half hour.

Package Included:
1x MiNi 3-axis gimbal
