Description:Link
Brand Name:DJI
Item Name:DJI Phantom 2 New version
Aircraft Specifications:
Weight (Battery & Propellers included): 1000g
Hover Accuracy (Ready to Fly): Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity: 200°/s
Max Tilt Angle: 35°
Max Ascent / Descent Speed: Ascent: 6m/s; Descent: 2m/s
Max Flight Speed: 15m/s(Not Recommended)
Diagonal Length: 350mm
Flight Time: 25mins
Take-off Weight: ≤1300g
Operating Temperature: -10°C ~ 50°C
Supported Battery: DJI Smart Battery
DJI Smart Battery Specifications:
Type: 3S LiPo
Capacity: 5200mAh, 11.1V
Charging Environment Range: 0℃ to 40℃
Discharging Environment Range: -20℃ to 50℃
2.4GHz Remote Control Specifications:
Operating Frequency: 2.4GHz ISM
Communication Distance (open area): 1000m
Receiver Sensitivity (1%PER): -97dBm
Working Current/Voltage: 120 [email protected]
Built-in LiPo Battery Working Current/Capacity: 3.7V, 2000mAh
H4-3D Gimbal Specifications:Link
Operating Current:Static current= 400mA (@12V)
Dynamic current= 600mA (@12V)
Input Power:3S~6S (12V ~ 26V)
Operating Temperature:-10°C ~ 50°C
Gimbal Weight:168g (Without camera )
Gimbal Dimensions (With Damping Unit):103mm X 92mm X 80mm
GCU Weight:22g
GCU Dimensions:42 mm X 32 mm X 9.3 mm
Supported Camera:GoPro Hero4 Black
GCU Input Power:3S~6S LiPo (12V~26V)
Assistant Software System Requirement
Windows XP SP3; Windows 7; Windows 8
Controlled Angle Accuracy:Pitch/Roll:±0.02°, Yaw: ±0.03°
Maximum Controlled Rotation Speed:Tilt axis: ±130°/s
Controlled Rotation Range:Tilt axis control:-130 ~ +45°
Regulatory Approvals:FCC (USA),CE (EU),RoHS (EU)
Usage:Compatible with most DJI platforms, including the Phantom 2 and Flame Wheel systems with the A2, WooKong-M, or NAZA-M flight controllers
Features:
DJI Phantom 2 New Version:
Ready to Fly, Multifunctional Quad-rotor System
Customized H3-2D and H3-3D H4-3D Gimbal Support
Precision Flight and Stable Hovering
25min Flight Time & Smart Battery
Auto Return-to-Home & Landing
Advanced Power Management
Intelligent Orientation Control (IOC)
Easy Battery Replacement
Self-tightening Propeller
Video Downlink Support
CAN-Bus Expansion Module
Zenmuse H4-3D Gimbal:
3-axis gimbal
High precision brushless servo control
Aluminum alloy body
Built-in independent IMU module
Small,lightweight,durable
A2, WKM, NAZA-M, NAZA-M V2 ,PHANTOM 2 supported
GoPro Hero4 Black supported
Trusted Zenmuse technology
Downloadable updates
Notice:
The H4~3D gimbal comes customized for the DJI Phantom 2. If you want to use it with the DJI Flame Wheel or other platform with DJI flight controllers, the independent GCU module is required. Note NAZA-M LITE is not supported, and a NAZA-M V2 PMU must be used if using a NAZA-M V1 flight controller.
Package Included:
1 x DJI Phantom 2 New RC Quadcopter
1 x Transmitter
1 x Charger
1 x Battery
1 x Manual
1 x Zenmuse H4-3D Gimbal
