Mini PX4 PIXFALCON Autopilot Flight Controller STM32F427 For RC Multirotors
Introudction:
The PIXFALCON, which can be recognized as a scaled-down version of the Pixhawk, is a high-performance autipoliot-on module suitable for fixed wing, multi rotors, cars, boats and other robotic platform. Compared with the Pixhawk, the Pixfalcon are some much more compact and light weighted but their functions and software compatibility are the same.
Processor:
32bit STM32F427 Cortex M4 core with FPU
168 MHz
256KB RAM
2 MB Flash
32 bit STM32F103 failsafe co-processor
Sensor:
ST Micro L3GD20H 16 bit gyroscope
ST Micro LSM303D 14 bit accelerometer/magnetometer
Invensense MPU 6000 3-axis accelerometer/gyroscope
MEAS MS5611 barometer
Interface:
1* UART (serail port)
Spektrum DSM/DSM2/DSM-X Satellite compatible input
Futaba S.BUS compatible input and output
PPM sum signal input
I2C
Internal microUSD port
Power system and protection:
Ideal power multiplexer with automatic current limit
All peripheral output over-current protected, all inputs ESD protected
Features:
168MHz/252 MIPS Cortex-M4F
14PWM/ Servo outputs (8 with failsafe and manual override, 6 auxiliary, high-power compatible).
Abundant connectivity options for additional peripherals (UART,I2C).
Integrated backup system for in-flight recovery and manual override with dedicated processor and standal-one power supply(fixed-wing use).
Backup system integrates mixing, providing consistent autopoliot and manual override mixing modes(fixed wing use).
Onboard safety switch and external safety switch
Multicolor LED main visual indicator
Package included:
1 x PIXFALCON Flight Controller
1 x 6-pin cable
1 x 4-pin cable
1 x safety switch
1 x RCIN cable
1 x output cable
