Mini APM Pro Flight Control with NEO-7N GPS&Power Supply Module for Multicopter
PM:
Description:
Mini APM Pro:
Using imported large current LDO instead of previous version 3.3V LDO to support outputting 500MA power.
Change the previous diodes to PIX PMEG2005 diodes and integrate the two-way output power
22UF/16V capacity was added into 5V module to ensure stable power of main controller (2560 part).
All ports have mounted on both ends and 2.54 standard Dupont connectors are adopted to create stability.
Two pieces R8-way PWM input signal has been simplified by 4pcs servo cable to realize signal input.GB led lights have replaced the PPM light, looks super flashing and dazzling
Size:60x38x14mm
NEO-7N GPS Module:
Receiver type:56 channels
GPS L1C/A
SBAS L1C/A
QZSS L1C/A
Time-To-First-Fix:
Cold Start:29s
Warm Start:28s
Hot Start:1s
Aided Start:5s
Sensitivity:
Tracking&Navigation:-161 dBm
Reacquisition:-160 dBm
Cold Start:-148 dBm
Warm Start:-148 dBm
Hot Start:-156 dBm
Horizontal position accuracy:Autonomous:2.5m
SBAS:2.0m
Accuracy of the time pulse signal:RMS:30 ns
99%:60 ns
Frequency of the time pulse signal:0.25Hz-10MHz(configurable)
Max navigation update rate:10Hz
Velocity accuracy:0.1m/s
Heading accuracy:0.5 degrees
Operational limits: Dynamics: not more than 4g
Altitude:50m
Velocity:500m/s
Power Supply Module:
Voltage Output:5.3V DC
Max Continuous Current:3A
Max Voltage Input:28V (1s-6S)
Max Measurable Current:90A
With BEC function:Yes
Interface:4P DuPont 2.54
Usage:for APM PRO/Pix Mini Interface
6-pos DF13 cable plugs directly to APM 2.5's 'PM' connector
Package Included:
1x APM Pro Flight Controller
1x NEO-7N
1x Power Supply Module
1x GPS Carrier
