Mini 1/3 CCD 700TVL 2.8mm 3.6mm Micro Camera 25*25mm for FPV Racer - 27.99 €

Mini 1/3 CCD 700TVL 2.8mm 3.6mm Micro Camera 25*25mm for FPV Racer
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

Mini 1/3 CCD 700TVL 2.8mm 3.6mm Micro Camera 25*25mm for FPV Racer


Description :
Item Name : 700TVL Camera
CCD: 1/3 Sony 960H CCD Sensor
Dimensions(mm): 25X25(W*L)
Pixel: PAL: 1020(H) x 596(V) 0.61MP;NTSC: 1020(H)×508(V)0.52MP
Effective Pixel: PAL: 976(H) x 582(V) 0.57MP;NTSC: 976(H)×494(V)0.48MP
Format : PAL/NTSC
Resolution(horizontal): 700TVL
DNR: 2DNR, support 0~15 16 grades
Min. Illumination: 0.01Lux/F1.2
Signal to Noise Ratio: ≥48dB
Video Output Amplitude: 1.0Vp-p / 75Ω
AGC : 0.25 / 0.50 / 0.75 / 1.00 adjustable four up to 55dB
White Balance Mode: On / Off selectable
Backlight Compensation: High brightness backlight compensation (HLC) / backlight compensation
Exposure Mode: Electronic exposure
Electronic Shutter: 1/50 (1/60) - 1/100000 sec
Gamma Correction: 0.45 / 1.0
Synchronous Mode: Internal synchronization
Audio: Optional
Working Voltage: DC12V ± 5%
Working Temperature: -20 ℃ - 60 ℃
Humidity: 0% to 96%
Package Included :
1 x 700TVL CCD Camera
1 x Cable
