Micro T700 700TVL CMOS Mini FPV Camera 2MP M8 2.1mm/2.3mm NTSC/PAL Black/Orange - 10.99 €

Micro T700 700TVL CMOS Mini FPV Camera 2MP M8 2.1mm/2.3mm NTSC/PAL Black/Orange
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

Micro T700 700TVL CMOS Mini FPV Camera 2MP 2.1mm/2.3mm NTSC/PAL Black/Orange
Description
Item Name : T700
Weight : 6.5g
Connector : JST-SH 1.0mm 3P

Resolution
Sensor : CMOS
Lens : 2.3mm / 2.1MM, M8
Horizontal Resolution : 700TVL
Pixel : PAL 1020H×596V (2MP) /NTSC 1020H×508V (2MP)
Effective Pixel : PAL: 976H×582V (2MP) /NTSC: 976H×494V (2MP)
Format : PAL/NTSC

Specification
Video Output : 1.0Vp-p/75Ω
AGC : 0.25/0.50/0.75/1.00 4 levels adjustable, max. up to 55db
WB : ON/OFF
Exposure Type : electronic exposure
Electronic Shutter : 1/50(1/60) - 1/100000 second
Gamma Correction : 0.45/1.0
Synchronization Mode : inter-sync
Working Voltage : DC3.3V-5V
Working Current : 70mA(low power consumption)
Temp. : -20℃--60℃
Operating Humidity : 0%~98%
Package Included
1 x Mini Camera
