Matek Micro PDB With 5V 12V Dual BEC Output For FPV Multicopter
The Micro PDB has been engineered to provide the highest possible performance and reliability in a 32*22mm & 4 layers PCB.
It distributes power from a battery pack to 4 ESCs, as well as providing dual synchronised & regulated DC outputs for powering
Cameras, Servos, RC receiver, Flight Controllers, Video Transmitters, LEDs, etc.
It offers a very compact solution to achieve 2A continuous output current over a wide input supply range(3S to 5S LiPo).
Description:
Brand: Matek
Item Name: Matek Micro PDB With 5V 12V Dual BEC Output
Input voltage range (3S-5S operation): 7 - 21V DC
Regulated 5V and 12V outputs
LED power indicators ( 5V & 12V outputs )
4 ESC outputs
ESC outputs:
Continuous current: 20A per output
Peak current (10 seconds/minute): 25A per output
BEC 5V output:
Designed for RC Receivers, Flight controllers, OSD, and Servos.
DC/DC synchronous buck regulator.
Voltage: 5.0 +/- 0.1VDC
Continuous current: 2 Amps (Max.2.5A 5s/minute)
Output Ripple: 40mV (VIn=16V, VOut=5V@2A load)
Short-circuit tolerant (5 seconds/minute)
BEC 12V output:
The battery should be 4S~5S LiPo (12.8~21V DC)
Standard output designed to power cameras and video transmitters,etc.
DC/DC synchronous buck regulator, Efficiency is up to 96%.
Voltage: 12.0 +/- 0.2VDC
Output Ripple: 20mV (VIn=16V, VOut=12V@2A Load)
Continuous current: 2 Amps (Max.2.5A 5s/minute)
Short-circuit tolerant (5 seconds/minute)
BEC 12V @ 3S LiPo
Output voltage= 3S LiPo voltage x 95%
Dimensions: 32 x 22 x 3 mm
Weight: 3.5g
Features:
2oz copper & 4-layers PCB.
ESC & Battery solder tabs in pairs
5V & 12V Output LED indicators & Short circuit tolerant
Micro size & lightweight
English Manual
Package Included:
1 x Matek Micro PDB With 5V 12V Dual BEC Output
