Matek 8 Bit WS2812B RGB 5050 Highlight LED for Naze32 CC3D
Description:
Brand Name:Matek
Item Name:WS2812B RGB 5050 LED
Voltage: about 5V
Ports: Digital
Size: 51x10 mm
Platform: AVR, Arduino,Naze32 / CC3D Flight Control (need to brush CleanFlight)
Features:
Built-in controller chip, only need an IO port to control multiple LED
Chip built-in shaping circuit,signal distortion is not cumulative, stable display
Trichromatic 256 brightness adjustment, scan frequency is not less than 400Hz / S
Serial connection-level interface, through a signal line to finish receiving and decoding data
Both ends have interfaces (DIN DOUT) that can be cascaded
Will show the flight control lock / unlock,left and right aileron, brake, throttle, alarm and other status.
Note:
If it is used for Naze32 or CC3D flight control,it need to brushed CleanFlight, and using PPM receivers.
Used for CC3D flight controller,you should pay attention to the following points:
-CC3D need to brushed CleanFlight firmware.
-Using PPM / SBUS receiver, you don’t use PWM receiver.
-GND 5V DIN behind the lights should connected to CC3D fifth row - + S of the motor output side.
-Choosing PPM receiver in the CF's assistant software configuration,then choose LED_STRIP options.
-Finally into the CF assistant software LED Strip Page to setup various states.
Package Included:
1x WS2812B RGB 5050 LED
