Martian 190mm 230mm 255mm 3mm Carbon Fiber Frame Kit with Power Supply Board
Specification:
Item name Specification Recommend Part Martian 190mm - Wheelbase: 190mm
- 3mm carbon fiber arm
- 1.5mmm carbon fiber fuselage
- Material: Carbon fiber
- Net Weight: 100g
- Package Weight:120g
- Size:230*10*4.5mm
Brushless motor:1806~2206(KV2000~2300)
Brushless ESC:10~20a
Flight controller:mini CC3D/ NAZA32/ F3
Battery:3S 1500~2200mah
Propeller:4030 4040 4045
Transmitter:5.8G 200~600wm 32CH
FPV Camera:sony 700TVL
Antenna:5.8G antenna Martian 230mm - Wheelbase: 230mm
- 3mm carbon fiber arm
- 1.5mmm carbon fiber fuselage
- Material: Carbon fiber
- Net Weight: 120g
- Package Weight:150g
- Size:230*10*4.5mm Brushless motor:1806~2206(KV2000~2300)
Brushless ESC:10~15a
Flight controller:mini CC3D/ NAZA32/ F3
Battery:3S 1500~2200mah
Propeller:5045 5030
Transmitter:5.8G 200~600wm 32CH
FPV Camera:sony 700TVL
Antenna:5.8G antenna Martian 255mm - Wheelbase: 255mm
- 3mm carbon fiber arm
- 1.5mmm carbon fiber fuselage
- Material: Carbon fiber
- Net Weight: 120g
- Package Weight:150g
- Size:230*10*4.5mm Brushless motor:1806~2206(KV2000~2300)
Brushless ESC:10~15a
Flight controller:mini CC3D/ NAZA32/ F3
Battery:3S 1500~2200mah
Propeller:6045 6030
Transmitter:5.8G 200~600wm 32CH
FPV Camera:sony 700TVL
Antenna:5.8G antenna
Feature :
Adapt 1.5mm thinkness body ,arm thinkness 3.0mm 3K carbon firber frame kit
With XT60 PCB power supply board
With camera tilt, inclination angle 25 ° -30 °
Package Included:
1 X Frame Kit
1 X Power supply board
