LS-F200KT 5.8G 40CH 800TVL AIO FPV Camera Transmitter 25mW/200mW/600mW VTX 120 Degree FOV
Features:
Integrates 800TVL camera, 5.8G 40CH VTX and 3dBi whip antenna
Wide angle of view - 120-degree FOV and 150-degree DFOV
NTSC / PAL switchable, 25mW / 200mW / 600mW switchable
Includes RaceBand, Band R for professional competition
Specifications:
Image sensor: 1/3 inch CMOS
Horizontal resolution: 800TVL
Lens: 150-degree M8
Angle of view: 120-degree FOV, 150-degree FOV
Min. illumination: 0.1 lux
TV system: NTSC / PAL switchable
Audio carrier: yes
Output impedance: 50 ohm
Output signal strength: 13 + / - 1dBm, 22 + / - 1dBm, 27 + / - 1dBm
Number of channels: 40 ( including RaceBand, Band R )
Antenna: 5.8G 3dBi
Power supply: 5 + / - 0.5V DC
Output power: 25mW / 200mW / 600mW switchable
Frequency
Band A58655845582558055785576557455725
Band B57335752577157905809582858475866
Band E57055685566556455885590559255945
Band F57405760578058005820584058605880
Band R56585695573257695806584358805917
Package Included
1 x 5.8G 40CH 800TVL FPV Camera
Package Included
1 x 5.8G 40CH 800TVL FPV Camera
