LKTR120 Micro Fiberglass FPV Quadcopter Frame With 4 DP03 7800KV Motors
Description:
Description:
OVERSKYRC developed a new motor named DP03, it is the smallest brushless motor specially for multirotor use in the world, it is also the smallest motor in the world that can drive 75mm propeller directly at high efficiency. You can use it both on 1S and 2S by changing propeller size accordingly.
Precification:
Test Data on 1S
Frame model:LKTR120
Motor model:DP03
Diameter of the motor:14mm
Frame model:LKTR120
Motor model:DP03
Diameter of the motor:14mm
Shaft:1.5mm
Screw hole spacing:8.5mm
Screw:M1.4*3
Motor weight:3.5g
KV:7800(black heat shrink tube)
Idle current:0.18A/3.5V
Max current:2.95A
Frame weight:14.1g
Motor to motor distance:120mm
Material:Fiberglass G10
Thickness of frame body:G10 1.5mm
Thickness of top plate:G10 1mm
Thickness of frame body:G10 1.5mm
Thickness of top plate:G10 1mm
Designer:LKTRSMG
Shipping Weight:50g
Test result on 75mm propeller:
3.7V/2.95A/45g thrust Full throttle
3.7V/1.20A/21g thrust Half throttle
3.7V/0.65A/13g thrust Below half throttle
Remark:
As it is a very small motor, propeller saver is not recommended, because the propeller saver will be too heavy compare with such a small motor, you can use a plastic tube on the shaft and push the propeller onto the shaft.
LKTR120 frame assembly:.
The building link is the following:.
LKTR120 frame assembly:.
The building link is the following:.
Package Include:
4 x 1.5mm pictch white connector
4 x DP03 7800KV motors
1 x LKTR120 Micro FPV Quadcopter frame
