Lantian 8 x WS2812B Driving LED Lights Board Strip Built-in Full-Color For NAZE32 CC3D
Lantian 8 x WS2812 Built-in Full-Color Driving LED Lights Board NAZE32 CC3D Available
Description:
WS2812B is the second generation with the built-in IC and 5050RGB lamp bead type with four feet.WS2812B's feet are less than WS2812 with 6 and the circuit is more conciseIt. It can be used for Naze32, CC3D flight control and can show the flight control lock / unlock, left aileron, brake, throttle, alarm and other status.
Feature:
- LED:5050 Package RGB full color highlighting WS2812B lamps*8
- Voltage:5V(4-7V)- LED:5050 Package RGB full color highlighting WS2812B lamps*8
- Size:51*10mm
- Port:Digital
- Platform:AVR, Arduino,Naze32/CC3D Flight Control(Refurbish to be CleanFlight)
- 5050 Highlight LED,Built-in control chip.It can control one or more LED with just only one IO port.
- Signal can Stable display and not cumulate in distortion with the Chip built-in circuit.
- Three primary level 256 can adjust brightness.
- 160000 color image display the effect.Not less than 400 HZ/S scanning frequency.
- Serial interface level can complete the data through a signal receiving and decoding.
- Highlight LED, high light color brightness uniformity.
- There are interfaces at both ends(DIN DOUT).They can be concatenated.
Remark:
- It need to refurbish CleanFlight and use PPM receivers when used in Naze32 or CC3D flight control.
- CleanFlight supports up to four lights, namely 32 WS2812B lamp beads.
- CC3W need Refurbish to be CleanFlight.
- Use PPM/SBUS receiver,PWM Receiver mismatch.
- Only match RC Quadcopter.
- Options election in CF assistant software:PPM Receiver,then check LED_STRIP
- Finally into the CF assistant software LED Strip Page Setup various states
Package Include:1 x Full-Color Driving LED Lights Board
