Specifications:
Max ESC number: 8
Size: 5 x 5cm
Weight: 8g
Fixing hole diameter: 3.5mm
This is a PCB board for easier wiring purpose, and does not include ESC or other accessories.
It makes the wiring of your multi-rotor system neater, nicer, securer.
Installation method:
1. Weld the power input wires of ESCs to the hub, suggested inner circle for "+", and outter circle for "-".
2. Isolate the hub with tape or shrinking tube, or use double side tape to fix it to the main frame of your multi-rotor aircraft.
Package Include:
1 x ESC Speed Controller Board
