Intelligent Charger For 2-10S(2.4-12.0V) Ni-MH/Ni-Cd Battery Pack
Description:
Charger for 2.4V/3.6V/4.8V/6.0V/7.2V/8.4V/9.6V/10.8V/12V Ni-MH or Ni-Cd rechargeable battery packs which connected in series by 2-10 cells.Intelligent recognize voltage of battery pack by its IC inside. Automatic stop after full charged.
Model: RC-1080
Input: AC 100~240V, 50/60Hz 0.2A
Output: 2.4-7.2V(2-6S): 800mA,8.4-12V(7-10S): 500mA
Reference Weight: 85g
Charge status:
Light in green: power on (standby) or fully charged
Light in red: in charging
Light flash in Green: Connect in wrong polarity or battery damaged, try to connect again.
Caution:Only charge the battery pack with the voltage between 1.2V-18V, make sure of the battery are in useful status.
Input
AC 100-240V 50/60Hz 0.2A(MAX)
Output
2-6 batteries set: 2.4-7.2V 800mA
7-10 batteries set: 8.4-12V 500mA
Cells of battery
2-10 cells adjustable manually
Terminal of battery capability
2-6 batteries set: about 5200mah
7-10 batteries set: about 3300mah
Charging mode
Pulse constant current charging mode
End charging mode
-dV,0dV,Tmax maximum of charging time
Pre charging time
2 min
The fastest charging time
8 hours
Protective function
Over voltage protection
Output short circuit protection
Over current protection
Opposite connection protection
Charger over heat protection
Indication light
No batter:green Charging:red
Full charge:green Battery problem:red
Usage temperature
0℃--40℃
Storage temperature
-20℃--70℃
Usage humidity
30%--85%
Storage humidity
30%--90%
Shape of outlook
Wall-mount
Output line
L=1.5m 24AWG UL2468
Output interface
Ф5.5/Ф2.5;1.2m,Corrugated balance cable
Weight
80g
Package Included:
1 x Intelligent Charger
