Immersion Duo2400 V3 2.4G 20CH Audio Video AV Diversity Receiver
Description: User Manual
Brand Name: ImmersionRC
Item Name: Duo2400 2.4G Receiver
Connector: SMA
Connector: SMA
Dimensions:90 x 103 x 23mm
Weight: 180g
Sensitivity: better than -90dBm
RF Impedance: 50 ohms
Frequency, Band 1: 2410, 2430, 2450, 2470, 2370, 2390, 2490, 2510MHz
Frequency, Band 2: 2414, 2432, 2450, 2468MHz
Frequency, Band 3: 2370, 2396, 2410, 2430MHz
Frequency, Band 4: 2396, 2396, 2410, 2430MHz
Audio: Stereo, Subcarriers on 6.0, and 6.5MHz
Modulation: FM, Audio and Video
Video Impedance: 75 ohms
Alarm: Low Battery, Programmable
Power Requirements: 6-13v
Power Consumption: ~300mA
Features:
20 Channel support, ImmersionRC/FatShark/Airwave, Lawmate
Exclusive high quality NexWaveRF receiver technology
Triple A/V output, for three viewing/recording devices
Simple button user interface, and remote control from the ground station
Dual independent receivers greatly increase usable range enhancing the FPV experience.
Designed for single-cable, plug and play integration with the ImmersionRC Antenna Tracker (v2) system.
Power, Audio, Video, and a bidirectional data link, are all passed through a single Mini-Din connector, connected to the Antenna Tracker.
Package Included:
1 x Receiver
2 x Antennas (3dBi 5.8Ghz omni-directional)
2 x 30cm RCA AV cables
1 x 1m DC Power cable
