iFlight SucceX F4 Flight controller OSD & 12A Blheli_S 2-4S Brushless ESC 16x16mm for RC Drone FPV Racing
Specification:
Brand name: iFlight
Item name: SucceX F4 Flight controller OSD & 12A Blheli_S 2-4S Brushless ESC
SucceX F4 Flight Controller
Single chip microcomputer: STM32F411
Gyro: MPU6000
UART port: 2
Firmware : MATEKF411
Mounting hole position: 16*16
Size: 21mm*21mm
Weight: 2.5g
SucceX Mirco 12A Brushless ESC
Input voltage : 2-4S LIPO
Continuous current: 12A
MCU: BB21F16G
BEC : None
ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
Size: 23mm*21mm
Mounting hole 16*16mm
Weight: 2.7g
Package Included:
1 x SucceX F4 Flight controller
1 x 12A Brushless ESC
Continuous current: 12A
MCU: BB21F16G
BEC : None
ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
Size: 23mm*21mm
Mounting hole 16*16mm
Weight: 2.7g
Package Included:
1 x SucceX F4 Flight controller
1 x 12A Brushless ESC
