Description:
You can hop to catch up with your fellows by grabbing this opportunity! The Ideafly Grasshopper F210 Professional Racing RC Quadcopter, which boasts a super high speed of 230km/h, has been invented by Ideafly, Flycolor and Gearbest, and intended for those who want to participate in the professional race.
We have researched for 6 months, revised the structural drawing for 5 times and made 10 samples to finalize the grasshopper design, for which we have already got an appearance patent.
We have also involved HMM, the professional racer who has taken part in international competitions, to set the parameters and modify the design. Therefore, the much more thrilling flight is capable of meeting the professionals' strict requirements.
Main Features:
- Amazing high speed of 230km/h. It can provide thrilling a racing experience that you are looking for. Faster than any other copter, it is an incredible frontrunner.
- Premium carbon fiber frame. Made of sturdy and durable carbon fiber, the upper board is 1.5mm thick, while the thickness of the arms and the board beneath them is 3.5mm.
- F3 10DOF flight controller with barometer and compass, which delivers you fantastic flight experience thanks to its next-generation CPU, no-compromise I/O, developer-friendly GUI, and compatibility with Oneshot. Enjoy having fun with one of the most excellent flight controllers.
Brilliant 2205 2300KV motors. With imported bearings processed through CNC and 100% dynamic balance, each of them can generate a thrust of up to 1,000g.
- Responsive ESCs. The ultralight Flycolor RAPTOR 390 BLHeli 2 - 4S 30A OPTO ESCs incorporate the most state-of-the-art MOS and 3-in-1 IC chip, which enable them to respond in no time. It supports setting parameters via BLheli software directly by connecting the F3 flight controller. You can set the parameters of 4 ESCs at the same time.
- Acceleration-indicating headlight. The brightness of the headlight varies according to the accelerator. The headlight flashes constantly, thus you can easily know how fast your copter will fly by glancing at the light.
Specifications:
Speed: max. 230km/h ( while using 14.8V 75C battery or larger power LiPo battery )
Product weight: 328g ( not including battery )
Flight controller: F3 10DOF
Motor: 2205 2300KV
ESC: Flycolor RAPTOR 390 BLHeli 2 - 4S 30A
instantaneous current 40A, continuous current 30A
Battery: 14.8V 1300mAh 45C 4S, XT60 Connector
Battery weight: 148g ( The product supports 75C battery. )
FPV transmitter: 5.8G 200mW 40CH
Camera: 700TVL, PAL
Charger: E4 Balance Charger
Propellers: 5045 three-blade and 5045BN two-blade
Headlight: 3W
Rear light: 3W ( It turns blue after code matching. )
Flight functions: going up and down, left and right, back and forth; 3D rollover; 3D inverted flight; rolling, encircling
You can hop to catch up with your fellows by grabbing this opportunity! The Ideafly Grasshopper F210 Professional Racing RC Quadcopter, which boasts a super high speed of 230km/h, has been invented by Ideafly, Flycolor and Gearbest, and intended for those who want to participate in the professional race.
We have researched for 6 months, revised the structural drawing for 5 times and made 10 samples to finalize the grasshopper design, for which we have already got an appearance patent.
We have also involved HMM, the professional racer who has taken part in international competitions, to set the parameters and modify the design. Therefore, the much more thrilling flight is capable of meeting the professionals' strict requirements.
Main Features:
- Amazing high speed of 230km/h. It can provide thrilling a racing experience that you are looking for. Faster than any other copter, it is an incredible frontrunner.
- Premium carbon fiber frame. Made of sturdy and durable carbon fiber, the upper board is 1.5mm thick, while the thickness of the arms and the board beneath them is 3.5mm.
- F3 10DOF flight controller with barometer and compass, which delivers you fantastic flight experience thanks to its next-generation CPU, no-compromise I/O, developer-friendly GUI, and compatibility with Oneshot. Enjoy having fun with one of the most excellent flight controllers.
Brilliant 2205 2300KV motors. With imported bearings processed through CNC and 100% dynamic balance, each of them can generate a thrust of up to 1,000g.
- Responsive ESCs. The ultralight Flycolor RAPTOR 390 BLHeli 2 - 4S 30A OPTO ESCs incorporate the most state-of-the-art MOS and 3-in-1 IC chip, which enable them to respond in no time. It supports setting parameters via BLheli software directly by connecting the F3 flight controller. You can set the parameters of 4 ESCs at the same time.
- Acceleration-indicating headlight. The brightness of the headlight varies according to the accelerator. The headlight flashes constantly, thus you can easily know how fast your copter will fly by glancing at the light.
Specifications:
Speed: max. 230km/h ( while using 14.8V 75C battery or larger power LiPo battery )
Product weight: 328g ( not including battery )
Flight controller: F3 10DOF
Motor: 2205 2300KV
ESC: Flycolor RAPTOR 390 BLHeli 2 - 4S 30A
instantaneous current 40A, continuous current 30A
Battery: 14.8V 1300mAh 45C 4S, XT60 Connector
Battery weight: 148g ( The product supports 75C battery. )
FPV transmitter: 5.8G 200mW 40CH
Camera: 700TVL, PAL
Charger: E4 Balance Charger
Propellers: 5045 three-blade and 5045BN two-blade
Headlight: 3W
Rear light: 3W ( It turns blue after code matching. )
Flight functions: going up and down, left and right, back and forth; 3D rollover; 3D inverted flight; rolling, encircling
Specifications
General |
Type: Frame Kit |
|---|---|
Motor |
KV: 2300 |
Connectivity |
Channel: No Transmitter
Remote Control: 2.4GHz Wireless Remote Control |
Battery |
Flying Time: 10-13mins
Charging Time (h): about 2.5 hours Battery Weight: 148g |
Camera |
Video Resolution: 700TVL (horizontal resolution)
Video Standards: PAL |
Dimension and Weight |
Product weight: 0.328 kg
Package weight: 0.550 kg Product size (L x W x H): 20.50 x 20.00 x 8.50 cm / 8.07 x 7.87 x 3.35 inches Package size (L x W x H): 41.00 x 27.00 x 11.00 cm / 16.14 x 10.63 x 4.33 inches |
Package Contents |
Package Contents: 1 x RC Quadcopter, 4 x Three-blade Propeller, 4 x Two-blade Propeller, 1 x Balance Charger, 1 x Balance Charger Cable, 1 x Power Adapter Cable, 1 x 5.8G Antenna, 1 x Instruction Disc, 1 x Battery, 1 x Carrying Bag |
You can download the following documents:
Ideafly F210 Racing Quadcopter User Manual
Ideafly F210 Racing Quadcopter Eye LED Connection Diagram
