HTIRC Hornet 2-6S 70A Brushless ESC With 5V/6A BEC For RC Airplane
![](/uploads/modules/catalog/img/18000/1503313586_298_htirc-hornet-2-6s.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/50/7F/d15d08c1-f73f-449b-b3a3-ac230118bdc7.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/8E/B5/139cb2cc-3e96-4048-a503-8755c81d76e0.jpg)
Description:
Brand Name: HTIRC
Series Name: Hornet
Item Name: 70A brushless ESC
Continuous Working Current: 70A
Burst Current: 90A (10s)
Peak Current: 180A
Operating Voltage: 2-6S Lipo (7-22.2V)
Dimension: 60x30x14mm
Weight: 50g (with cable)
BEC Type: SBEC
BEC Output Voltage: 5.0V
BEC Current: 6.0A
Programmable: Yes
Feature:
Smaller size,lighter and lower calorific value than other ESC that with same current specification.
Automatically adjust the throttle stroke.
Use imported three-terminal regulator or high-quality power management module to provide BEC voltage, with a strong ability to load and BEC output With short circuit protection,undo short circuit to restore the output.
8-layer PCB board, lower internal resistance, less heat.
English Manual,
Package Included:
1x Htirc Hornet Series 70A ESC
