Holybro TekkoS 4 in 1 30A BLHeli_S ESC 3-6S Built-in Current Sensor For RC Drone FPV Racing Multi Rotor
The TekkoS 4 in 1 electronic speed controller (ESC) provides the power of BlHeli_S performance in a slim package. This makes your electronic stack slim, and generally eliminates the need for an additional PDB. The 4 in 1 ESC performs great and helps clean up any build.
The TekkoS 4 in 1 is also extremely easy to install. It is compatible with 3s through 6s batteries and has a built-in current sensor that hooks up directly to the Kakute F4 to provide mAh information. The TekkoS connector directly to the Kakute F4 flight controllers connector and also sends voltage.
Description:
Brand name: Holybro
Item name: TekkoS 4 in 1 30A BLHeli_S ESC
Con. Current: 30amp continuous draw per motor
Peak Current: 40amp
BEC: no
Lipo input: 3-6S
MCU: BB21
Firmware: 48Mhz Runs BLHELI_S J_H_xx firmware
Mounting hole spacing: 30.5mm x 30.5mm
Features:
BlHeli_S
D-Shot ready
Built in current sensor
Connector to flight controller
Current and voltage sent to flight controller
Easy install
High-quality components
Supports damped light
NO external capacitors needed
Package included:
1 x TekkoS 4 in 1 30A BLHeli_S ESC
1 x 8pin JST 1mm pitch 70mm cable
