Note:This item is APAC version,can only be used at Asia-Pacific area,if you want to use it at other areas,please use a 3A UBEC for external power supply.Here are two UBEC we recommended for power supply.
Hobbywing 5V/6V 3A UBEC,
External brushless 5V 3A UBEC,
Specification:
Brand:Hobbywing
Model Number:XRotor-50A
Cont.Current:50A
Burst Current(10sec):70A
BEC:None
Lipo:2-6S
Programming:Timing(high/middle),LED Light(on/off),LED Light Color(red/green),Motor Rotation(CW/CCW)
Weight:46g
Size:48x30x15.5mm
Plug:Φ3.5mmx3
Usage:RC Multicopter
APAC means Asia-Pacific Version,the official ESC sold in Asia-Pacific areas.
Features:
- Using Multicopter special program, fast throttle response,surpasses all kinds of open source software;
- Firmware was optimized specifically for disc motor, and it has a very good compatibility;
- Highly intelligent, strong adaptive capacity, reserve the timing setting item (height/middle timing), easy to use;
- Throttle signal line is twisted wire to reduce crosstalk within the transmission signal generated by the copper, so that more stable flight;
- Supports refresh rates up to 621Hz throttle signal, compatible with various flight controllers. (Note: the throttle signal over 500Hz are all non-standard throttle signal);
- Using MOSFET special driver IC, its performance and stability far surpass the driving circuit with discrete components built;
- Ultra-low resistance MOSFET, strong flow capacity.
English manual
Package Included:
1x Hobbywing XRotor 50A brushless ESC
