Hobbywing XRotor 15A Brushless ESC 2-3S For RC Multicopters APAC Version
Feature:
- Special core program for multi-rotor controllers meets various functional requirements against multi-rotors;
- Specially optimized software for excellent compatibility with disc-type motors;
- DEO (Driving Efficiency Optimization) technology significantly reduces the ESC temperature, improves the throttle response, and strengthens the stability and flexibility of multi-rotors. This ESC is quite suitable for QAVs (The motors slow down rapidly, especially when reducing the throttle amount)
- Compatible with “Regular” signal-receiving mode (that is the ESC can receive regular throttle signals range from 1100μs to1940μs) and “One Shot” signal-receiving mode (that is the ESC can receive fixed throttle signals range from 125μs to250μs);
- The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable;
- In “Regular” signal-receiving mode, the ESC is compatible with various flight-controllers and supports a signal frequency of up to 500Hz;
Specifications:
Model Con. Current Peak Current(10s) BEC LiPo Parameter Options Weight Size Typical Application*
(For reference) XRotor-15A 15A 20A No 2-3S Timing
(Medium/High) 10.5g 47x17x8.3 mm 200/250 class Multicopters
Test:
250 QAV Motor SunnySky 1806 EMAX1806 KV Rating 2000KV 2300KV 1430KV 2280KV Propellers(2-blade) 5043 6040 5043 6040 5030 6040 5030 6040 Voltage 11.1V 7.4V 11.1V 11.1V 7.4V 11.1V 7.4V 11.1V 7.4V 11.1V 7.4V 11.1V 11.1V Max.Current 6.3A 6.1A 11.3A 9.4A 8.6A 15.4A 1.6A 2.7A 2.3A 4A 4.4A 8A 11.3A Recommended ESCs 10A 10A 15A 15A 15A 20A 10A 10A 10A 10A 10A 15A 15A
Model Con. Current Peak Current(10s) BEC LiPo Parameter Options Weight Size Typical Application*
(For reference) XRotor-15A 15A 20A No 2-3S Timing
(Medium/High) 10.5g 47x17x8.3 mm 200/250 class Multicopters
Note:
1. For 250 or 300 class multi-rotors, we recommend using 1806 size or 2204 size motors and 5 inch or 6 inch propellers. (Because bigger propellers or motors may cause the ESCs to get burnt because of overload, so users need to take the risk themselves if they persist in using propellers or motors beyond our recommendation.).
2. The "Typical Application" in the above form only refers to quadcopter (with 4 motors). When the ESCs are installed on multi-Rotors with 6/8/16 motors, the applicable axle distance can be larger than the value listed in the above form.
Test:
250 QAV Motor SunnySky 1806 EMAX1806 KV Rating 2000KV 2300KV 1430KV 2280KV Propellers(2-blade) 5043 6040 5043 6040 5030 6040 5030 6040 Voltage 11.1V 7.4V 11.1V 11.1V 7.4V 11.1V 7.4V 11.1V 7.4V 11.1V 7.4V 11.1V 11.1V Max.Current 6.3A 6.1A 11.3A 9.4A 8.6A 15.4A 1.6A 2.7A 2.3A 4A 4.4A 8A 11.3A Recommended ESCs 10A 10A 15A 15A 15A 20A 10A 10A 10A 10A 10A 15A 15A
250/300 QAV Motor T-MOTOR 2204 SunnySky 2204 EMAX1806 KV Rating 1400KV 2300KV 2300KV 2300KV Propellers(2-blade) 5043 6020 5030 6020 5043 6040 5030 6030 Voltage 11.1V 11.1V 11.1V 7.4V 11.1V 11.1V 11.1V 12V 8V 12V Max.Current 2.3A 3A 9A 5.7A 10.2A 7.8A 12.2A 7.5A 6.4A 11.5A Recommended ESCs 10A 10A 15A 15A 15A 15A 20A 15A 10A 15A Note:
1806 size and 2204 size motors have been widely used on the 250/300 level QAVs. The operating currents will be quite different when paring the same ESC with different batteries (2S/3S) and propellers. Please select the right ESC as per the typical parameters listed out below.
Package Include:
1xHobbywing XRotor 15A ESC
