Hobbywing RPM Sensor For High-Voltage ESC Speed Controller

Specification:
Brand Name: Hobbywing
Item Name: RPM Sensor
Working voltage: 3.5 - 8.4V (1 - 2S Lipo)
Current: 1 - 5mA
Voltage range of the motor wires: 2 - 14S Lipo
RPM range (for 2 poles brushless motor): 1000rpm - 300000rpm
Working temperature: 0 - 50 Celsius degree or 32 - 122 Fahrenheit degree
Size: 23x 10 x 2mm
Weight: 6g (Input and output wires are included)

Features:
RPM Sensor For Hobbywing High-Voltage ESC,
It detects the voltage changes at the wires of brushless motor, and then outputs the RPM signal. This RPM sensor can work with some speed control systems for helicopters. And one of its typical applications is to work as the RPM sensor for V-Bar system made by Mikado

Package Included:
1 x Hobbywing RPM Sensor
