Hobbywing Quicrun 10BL60-sensored 60A Sensored Brushless ESC for RC Car
Description:
Brand: Hobbywing Quicrun
Item name: 10BL60-sensored 60A Sensored Brushless ESC
Cont.current: 60A
Peak current: 380A
Input: 4-9 cells NiMH or 2-3S Lipo
BEC Output/Operating voltage of the cooling fan: 6V@2A,linear mode / 6V (the cooling fan gets its power supply from the built-in BEC)
Resistance: 0.0008
Motor supported: sensored and sensorless brushless motor
Cooling fan: 6V (the cooling fan gets its power supply from the built-in BEC)
Weight: 59g (with wires, without cooling Fan)
Size: 33(L)x28(W)x31.5(H, with cooling fan)mm
Motor limit: 4-6 cells NiMH/2S Lipo
Car applicable: 1/10 & 1/12 On-road / Off-road / F1 / Drift car race / Street race for fun / Club racing / STOCK race with 0 timing / Drift car race
Motor limit:
For 4-6 cells NiMH/2S Lipo
For 4-6 cells NiMH/2S Lipo
≥8.5T(1/10 On-road), ≥13.5T(1/10 Off-road) *"T" indicates the limit value of motor turns when
the ESC timing is set to 0. The larger the timing, the more turns the motor needs.
8-9 cells NiMH/3S Lipo
≥13.5T(1/10 On-road), ≥17.5T(1/10 Off-road) *"T" indicates the limit value of motor turns when
the ESC timing is set to 0. The larger the timing, the more turns the motor needs.
Features:
For: 1/10 & 1/12 On-road / Off-road / F1 / Drift car race / Street race for fun / Club racing / STOCK race with 0 timing / Drift car race.
High performance but low price, users can own this reliable race-ready ESC at an affordable cost.
Compact size, suitable for various car chassis.
Auto identification system can recognize sensored / sensorless brushless motors automatically.
Excellent operating feelings and plentiful adjustment options, suitable for most kinds of competitions.
8 steps of timing adjustment greatly increase the output power of the motor, and unlock its maximum potential.
Proportional brake with 4 steps of Maximum Brake Force adjustment, 8 steps of Drag Brake Force adjustment and 4 steps of Initial Brake Force adjustment.
9 steps of acceleration (punch) adjustment, from “soft” to “very aggressive” to fit for different kinds of cars, tires and tracks.
Multiple protections: Low voltage cut-off protection for Lipo or NiMH battery / Over-heat protection / Throttle signal loss protection / Motor Lock-up protection.
One-button (the “SET” button on the ESC) to set the ESC, and easy to reset all parameters to the factory default settings.
Compatible with the optional device ---- the portable Digital LED Program Card, especially convenient for outdoor use.
ESC manual,.
Package Included:
1 x 10BL60-sensored 60A Sensored Brushless ESC
