Hobbywing Quicrun 1/10 WP-10BL60 Brushless Waterproof 60A ESC
Description:
Brand: Hobbywing Quicrun
Item name: Brushless Waterproof 60A ESC
Cont./Peak current/ resistance: 60A/360A/0.001Ω
Motor type supported: sensorless brushless motor
Car applicable: 1:10 on-road/off-road/buggy/monster
Motor Limit:
For 2S Lipo or 6 cells NiMH:
1. On-road: 3656-size or smaller motor with the KV<6000
2. Off-road/Buggy/Monster: 3656-size or smaller motor with the KV<4000
For 3S Lipo or 9 cells NiMH:
1. On-road: 3656-size or smaller motor with the KV<4000
2. Off-road/Buggy/Monster: 3656-size or smaller motor with the KV<300
Battery: 4-9 cells NiMH / 2-3S Lipo
BEC output: 6V/2A (Linear Mode)
Size/ Weight: 48.5(L)x38(W)x32(H) / 90g
External program port: available
Working voltage of fan: from battery directly without regulating
Features:
For: 1:10 on-road / off-road / buggy / monster
Water-proof and dust-proof for all-weather races.
(Note: please uninstall the cooling fan before using this ESC in water; Clean and dry it soon after the use for avoiding the connectors get rusty.)
Proportional brake with 4 steps of maximum brake force adjustment and 8 steps of drag brake force adjustment.
9 steps of acceleration (/punch) adjustment from “soft” to “Very aggressive” to fit for different kinds of models, tires and tracks.
Multiple protections: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor lock-up protection.
One-button (the “SET” button on the ESC) to set the ESC, and easy to reset all parameters to the factory default settings.
Compatible with the optional device - the portable Digital LED Program Card, especially convenient for outdoor use.
ESC user manual, .
Package included:
1 x Brushless ESC
1 x Manual
