Description:
The 3A-UBEC is a switch-mode DC-DC regulator
supplied with a 2-6 cells lithium battery pack (or 5-18 cells NiMH /NiCd battery ),
it outputs a consistent safe voltage for your receiver, gyro and servos.
It is very suitable for RC helicopter.
Compared with the linear mode UBEC,
the overall efficiency of the switch-mode UBEC is much higher.
Specification:
1.Output Voltage:5V/3A or 6V/3A (Changeable with an output-voltage select switch )
2. Continuous output current: 3 Amps
3.Input: 5.5V-26V (2-6 cells lithium battery pack or 5-18 cells NiMH /NiCd battery)
4. Size: 43mm*17mm*7mm (L*W*H)
5. Weight: 11g
Features:
1. Advanced switch mode DC-DC regulator IC.
2. Powerful output even working with 4 to 6 cells Lipo battery.
3. Battery polarity reversal protection.
4. A metal shield covers almost all the electronic components.
5. The working status is shown by an indicator (LED).
Package Included:
1X Hobbywing 5V/6V 3A Switch-Mode Ultimate BEC (UBEC)
