Multifunction LCD Program Box Program Card for ESC
1 Working Modes
1.1 Works as an individual device to set the ESC, the value of each parameter is displayed on the LCD screen.
1.2 Works as an USB adapter to link the ESC with a PC to update the firmware of the ESC or set the ESC by HOBBYWING USB LINK SOFTWARE .
1.3 Works as a Lipo battery voltmeter to measure the voltage of the whole battery pack or each cell.
2 Specifications
2.1 Size: 90mm (L) * 51mm (W) * 17mm (H)
2.2 Weight: 65g
2.3 Input Voltage: 4.5-12.6V
(If the ESC hasn’t a built-in BEC, you must use an additional battery pack to supply the program box)
2.4 Displayer: 16*2 characters LCD.
2.5 Interface: Mini USB interface, ESC interface (Futaba plug), Power supply interface (Futaba plug)
3 Compared with the "2 in 1 Professional LCD Program Box"
Models of LCD program boxes:
*2 in 1 Professional LCD program box (Already stopped)
*Multifunction LCD program box: It is a new priduct uses MCU (microprocessor) with larger memory, it has a new function to work as Lipo battery voltmeter to measure the voltage of the whole battery pack and each cell.
Firmware for the LCD program boxes:
*2 in 1 Professional LCD program box:
It has 2 types of firmware
a) Type A: The firmware with postfix “_V3” (eg. V1.11_120331_V3) is only suitable for XERUN-120A-SD V3 and V3.1 ESC
b) Type B: Firmware without postfix “_V3” (eg. V1.08_120504) is suitable for the ESC below except the XERUN-120A-SD V3 or V3.1 ESC.
ii. EZRUN series V2.0 car ESCs;
iii. Platinum series aircraft/helicopter ESCs.
iiii. Platinum V3 series aircraft/helicopter ESCs.
*Multifunction LCD program box:
Because of its larger memery size, a single firmware can be compatible with all speed controllers, including XERUN series V2.0/2.1/3.0/3.1, EZRUN V2.0, Platinum series and Platinum V3 series.
User Manual: PDF
Package Includes:
1 x Program Card for ESC
1 x USB Cable
