Hobbywing 2-3S External 8A MAX 15A UBEC Switch Mode
Description:
The 8A-UBEC is a switch-mode DC-DC regulator works with a 2-3S Lipo battery, it outputs a consistent safe voltage for your receiver, gyro and servos.
It is very suitable for large scale RC models with many servos such as nitro powered RC helicopters and airplanes.
Specification:
Brand Name: Hobbywing
Item Name: External 8A UBEC
Output Voltage: 5V or 6V (Changeable with a switch )
Continuous output current: 8 Amps
Burst output current: 15 Amps
Input: 6V-12.6V (2-3S Lipo battery)
Quiescent current: 60mA
Size: 42mm*39mm*9mm (length*width*height)
Weight: 36g
Features:
- Uses advanced switch-mode DC-DC regulator IC.
- The output current is very large to supply all electric equipments.
- Output short-circuit protection function.
- A metal shield and a filter significantly reduce the electromagnetic interference.
- Automatically detects the amount of the Lipo battery pack (2S or 3S).
- Shows the battery capacity with 4 LEDs.
- Shows the working status with a LED, it lights when the UBEC works normally.
- There are 2 output leads to reduce the resistance when connecting the UEBC to the receiver.
- With a step-down voltage regulator of 0.7V down as accessory (It changes the output from 6.0V to 5.3V for some special equipments that cannot work with 6V inputs).
English Manual,
Package Included:
1x Hobbywing 8A UBEC
