Hisky H-4Q 2.4G 4CH 3Axis/6 Axis Gyro LCD Transmitter
Description:
Item Name:Hisky H-4Q 2.4G 4CH 3Axis/6 Axis Gyro LCD Transmitter
Brand:Hisky
Item No:H-4Q
Note:This transmitter can bind with the Hisky HFP100/HFP100 V2/HFP80/HFP80 V2/FBL90 FBL70 V955 V944 HMX120 Helicopter.
H-4Q transmitter specification:
(1)Channels:4
(2)Resolution:1024
(3)Frequency:2.4 GHz ISM frequency range
(4)Modulation:GFSK
(5)Spread spectrum mode:FHSS
(6)Number of frequency channels:20
(7)Hopping rate:240 jumps/s
(8)Output power:<=20dBm
(9)Working current:<=150mA
(10)Operation voltage:1.2Vx4 NiCad/NiMH
(11)Dimensions:150mmx188mmx70mm
(12)Net weight:320g
H-4Q transmitter features:
(1)Utilizes 2.4GHz Frequency Hopping Spread Spectrum(FHSS)technology
(2)Digital trim
(3)Dual rates on aileron,elevator and rudder.
(4)Low voltage warning
XY5000S Receiver specification:
(1)Channel:5
(2)Frenquency:2.4Ghz ISM frenquency range
(3)Modulation:PCM
(4)Spread spectrum mode:FHSS
(5)Operation voltage:4.5-5.5v
(6)Operation current:<=30mA
(7)Net weight:11g
(8)Product size:41mmx28mmx14mm
XY5000S Receiver features:
(1)2.4Ghz FHSS technology
(2)High reception sensitivity,high resistance to interference
Package Included:
1 x H-4Q transmiter
1 x XY5000S Receiver
Here is the manual in English&Chinese,please click it:
