Guide Betaflight 3.1.0 Micro F3 Flight Controller 16x16mm 1.8g Built-in 5V/1A BEC
Description:
Item name: Guide Betaflight 3.1.0 Micro F3 Flight Controller
Size: 20x20mm
Mounting holes: 16x16mm, φ2.0mm
Weight: 1.8g
Firmware: betaflight_3.1.0_OMNIBUS
CPU: STM32F303CCT6 (72MHZ, 256K FLASH)
Sensor: SPI Sensor MPU-6000 triaxial accelerometer / triaxial gyroscope
Power supply: 2-4S Lipo (8.4-16.8V)
BEC: built-in 5V/1A
Buzzer port: with
OSD function: no
Usage: for 60mm Micro FPV racing frame
Receiver configuration:
SBUS or DSM receiver input, please configurate RX3 as input interface.
DSM receiver powered from 3.3V
SBUS and PPM from 5V
Receiver:
Supports Sbus or serial port RX port, Spektrum 1024/2048, SBUS, XBUS, SumD and SumH RX, built-in inverter.
Supports 3.3v Spektrum satellite receiver
Supports PPM receiver
Features:
Runs betaflight_3.1.0_OMNIBUS, the latest firmware that supports Dshot ESC drive.
Uses the MPU6000 over SPI for the best possible flight performance.
With buzzer port
Supports LED Sprit (turn off Transponder before using)
Supports BLheli suite ESC programme
Built-in voltage detection and alarm function
Package included:
1 x Guide Betaflight 3.1.0 Micro F3 Flight Controller
