Overview:
I am very pleased to introduce SPAN PRO F4 BL32 Tower, which is mainly upgraded for the ESC adjustment part,Support 6S Lipo Input, Max 8s. The flight control section has been upgraded to V2.0, which fixes some known problems. FPV Quadcopter's electronic equipment is basically integrated into two boards, which can greatly reduce assembly time and better layout of quadcopter.
Specifications:
FC&VTX Board:
Model: GEP-F405-VTX58800-2.0
MCU: STM32F405 168M
IMU: MPU6000 gyro/accelerometer (SPI)
Firmware Version: OMNIBUSF4SD
Channel: 48CH(IRC Tramp default UART3)
VTX Power: PIT/25/100/200/600/800mW
OSD: BetaFlight
Input Voltage: 3-6S Lipo(MAX 8S)
BEC Output:5V@2A
Size: 36x36mm board
Mounting hole: 30.5x30.5mm/Ф4mm
Weight:11g
Integrated LC Filter
4IN1 50A BLHeli_32 ESC Board:
Model: GEP-BL32-50A-4IN1
PDB: Integrated
Battery Monitoring: Integrated
Current sensor:Support
Input Voltage: 3-6S Lipo(MAX 8S)
BEC: NO
Con. Current: 50A
Burst Current: 55A (5S)
Support DSHOT1200/DSHOT600, PWM, Multishot, OneShot
Firmware Version:GEPRC-BL32-4IN1
Mounting hole: 30.5x30.5mm/Ф4mm
Size:36*36mm
Copper thickness: 4OZ*4(Power Layer)+2OZ*2
weight:15g
Features:
Model:SPAN PRO F4 BL32 Tower
MCU:STM32F405 168M
IMU: MPU6000 gyro/accelerometer (SPI)
Con. Current: 50A
Burst Current: 55A (5S)
Input Voltage: 3-6S Lipo(Max 8S)
FC firmware Version: OMNIBUSF4SD
ESC firmware Version:GEPRC-BL32-4IN1
Size: 36x36x14mm
Mounting holes: 30.5mm
Installation height:14mm
Copper thickness:4OZ*4(Power Layer)+2OZ*2
Support DSHOT1200/DSHOT600, PWM, Multishot, OneShot
Channel:48CH(IRC Tramp default UART3)
VTX Power:PIT/25/100/200/600/800mW
High precision CNC heat sink.
On-Board LC Filter for clear video images
Practical - Easy to access connectors
Configurable - Choose to use connectors
Professional - Symmetrical, Neat and Tidy and Easy to install in Most of frame.
Toal weight: 26g(FC&VTX+ESC)
Package Included:
1 x FC&VTX Board
1 x ESC board
1 x Antenna
1 x Capacitor
1 x MMCX Antenna for easy replacement and upgrades
1 x 4pins JST-SH sockets (PPM, PWM, SERIAL RX, GPIO, ADC, 3V, 5V, GND)
1 x 4pins JST-SH sockets with BUZZER & WS2811 RGB LED
1 x 4pins JST-SH socket for Video and Audio transmission
1 x power wire XT60
