GB - 130 Carbon Fiber DIY Frame Kit with SP Racing F3 ACRO 6DOF FC

GB - 130 Carbon Fiber DIY Frame Kit with SP Racing F3 ACRO 6DOF FC
Seller: GearBest,
Description:
The racing quadcopter is an X-frame style racing designed and manufactured by professional manufacturer
This frame kit is a set of spare part of quadcopter or DIY copter part, which is made from high-quality carbon fiber. Due to this good material, we're allowed to create a sturdy yet lightweight structure
This frame is very difficult to break and very well balanced for a fun flying experience

Main Features:
- This frame has proven to be extremely durable, affordable and sleek design
- Full carbon fiber frame kit, which is ultralight and with great intensity

Specifications:
Airframe specifications:
Model: GB - 130
Material: 3K carbon fiber
Arm plate thickness: 3mm
The airframe plate thickness: 2mm
Wheelbase: 130mm

Motor specifications:
Framework: 9N12P
KV: 4000KV
Thrust: 70g ( more than the same level motor )
Max. thrust: 315g
Prop adapter shaft thread: M5
Propeller: 3 inch
Nut color: black
Height: 28mm / 1.1 inch
Diameter: 18mm / 0.7 inch
Net weight: 20g

ESC specifications:
Brand name: DYS
Item name: ESC
Item No.: XM10A
Input voltage: 1 - 3S LiPo
BEC: NO
Firmware: BLHeli
Size: 23 x 12 x 4.5mm
Weight: about 4.5g

Camera specifications:
Lens: 2.8mm
OSD SET: yes
S / N Ratio: more than 60dB
Auto gain control ( AGC ): yes
WDR: D-WDR
DNR: 2DNR
Power: 5 - 17V DC
Dimension: 30 x 26 x 39mm / 1.2 x 1 x 1.5 inch
Net weight: about 55g

Antenna specifications:
Brand name: Aomway
Item name: 5.8G 4 leaf clover RHCP antenna
Connector: RP - SMA male
Frequency: 5.8G
Gain: 3dBi
SWR: less than 1.5

Specifications

General

Type: Frame Kit

Motor

KV: 4000
No. of Cells: 3 - 4S

Camera

Camera Pixels: 600TVL
Video Standards: PAL

Dimension and Weight

Product weight: 0.420 kg
Package weight: 0.500 kg
Product size (L x W x H): 13.00 x 13.00 x 6.00 cm / 5.12 x 5.12 x 2.36 inches
Package size (L x W x H): 28.00 x 17.00 x 8.00 cm / 11.02 x 6.69 x 3.15 inches

Package Contents

Package Contents: 1 x Frame Kit, 1 x Flight Controller, 1 x Antenna, 1 x Camera, 1 x Transmitter, 4 x Motor, 4 x ESC, 2 x CW Blade, 2 x CCW Blade
