Gartt GT450 DFC Torque Tube Version RC Helicopter Kit With Canopy and Blade
GARTT DFC 450TT 3D Electric Helicopter Kit (Align T-rex Compatible).Take a close look at the head and tail of this awesome machine. It's ultra light, yet rigid design is strong enough for even the most skitzophrenic of 3D helicopter pilots!
Description:
Length: 635mm
Height: 230mm
Main Rotor Diameter: 710mm
Tail Rotor Diameter: 158mm
Motor Drive Gear: 13T
Main Drive Gear: 150T
Autorotation Tail Drive Gear: 106T
Tail Drive Gear: 25T
Drive Gear Ratio: 1:11.5:4.24
Weight (w/o power system): 530g
Flying Weight: Approx. 640g
Features:
• Newly designed DFC low wind resistance rotor head assembly with reduced distance between rotor head and frame, effectively lowering the CG for better 3D performance.
• Single piece integrated design of main bearing block and servo mount.
• Single piece integrated design of anti-rotation guide and gyro mount.
• Single piece integrated landing gear.
• Newly designed high resolution swashplate.
• Single piece battery mount with integrated canopy mount designed to bring CG closer to disk plane.
• Highly rigid frame with single piece carbon side and bottom plates.
• Highly efficient shaft driven tail design.
• Weighted tail rotor blade grips to repel centripetal forces.
• Straight-up in-frame alloy rudder servo mount for improved geometry and better CG.
• Newly designed fiberglass canopy.
• Newly designed high strength main blade grips.
• Upgraded metal tail slider and tail slider control arm.
Package Includes:
1 x GARTT DFC 450TT Helicopter Kit (All Necessary Hardware)
1 pair Fiberglass Main Blades
1 x Fiberglass Canopy
Required items:(Not included)
Lipoly Battery (2200mAh 3S)
Brushless Outrunner Motor
Flybarless Control Unit
Receiver
Servos
ESC
