FX FX796T FX799T Micro 5.8G 40CH 200mW AV Race Transmitter
FX799T ordinary angle :
Attention please! This kind of transmitter comes with SMA-Female connector, photos are for reference only. (update date: November 6th, 2015)
Attention please! This kind of transmitter comes with SMA-Female connector, photos are for reference only. (update date: November 6th, 2015)
FX796T vertical angle:
Easy to use single button, LED interface. It also comes with a clean pre-wired harness, and only weighs 7.5g! It stays cool to the touch during operation, so you don't have to worry about it overheating in a crash.
Description:
Brand: FX
Item name: 5.8G 40CH 200mW AV Race Transmitter
Modulate: Wideband FM Modulate
Video Format: NTSC/PAL
Output Impedance: 50 Ohm
Output Power: 23dBm
Channel: 40 CH
Operating Voltage: 12V (7V-20V)
Supply Current: 200mA
Operating Temperature: -10~85°C
Video Band Width: 0~8.0 MHz
Audio Carrier Frequency: 6.5 MHz
Video Input Level: 0.8~1.2 Vp-p
Video Input Impedance: 75 Ohm
Audio Input Level: 0.5~2.0 Vp-p
Audio Input Impedance: 10K Ohm
Connector: SMA Female (need to use SMA Male antenna)
Dimension(L X W): 31mm x 20mm
Weight: 7.5g
Package included:
1 x 5.8G 40CH 200mW AV Race Transmitter
1 x Antenna
1 x Cable
