Futaba T6K T-FHSS Air 2.4Ghz 6CH S.Bus Transmitter With R3006SB Receiver
You'll be hard pressed to find another 6-channel system with as many functions as the 6K at a comparable price. Telemetry sensors monitor critical flight data, including temperature, RPM, altitude, receiver battery voltage, external voltage and variometer. It's compatible with S.Bus and S.Bus2 servos, and setting functions can be programmed through the transmitter. Controls are positioned to be within easy reach, and the menu is a breeze to navigate. Throw in other features such as 30 model memory, a 128x64 DOT backlit LCD screen and updateable software, and it's easy to see how the 6K is a lot of radio for the money
Description:
Brand:Futaba
Item No.:T6K,R3006SB
Item Name:Transmitter & Receiver
Type: 2-stick, 6-channel, T-FHSS/S-FHSS selectable
Power Supply: Optional 6V Nimh's or 6.6V Lithium (LiFe) batteries
15-model memory
Function Voice Telemetry
10-character model naming
Trims: with storage of digital values
Functions: (ATV / EPA) by the end of servo travel adjustment
Stroke Servo: 3 settings and exponential function (EXP)
4 switches / potentiometer 1
Failsafe: adjustable lanes 1-6
Mixes planes and helicopters
T-modulation T-FHSS / S-FHSS / FHSS
Stopwatch
Offset neutral
Trainer Mode
Monitor servos
Alarm Adjustable battery under multiple voltages
Audible and vibrating alarms
Port S-BUS
System features
S-FHSS/T-FHSS selectable
Telemetry system (T-FHSS) with data speech function for monitoring receiver battery voltage, external voltage, temperature, RPM, altitude and variometer
Built-in antenna
S.Bus/S.Bus2 servo setting functions programmable through the transmitter
Preset vibration alarms
30 model memory
8-character model/user naming
Programmable mixes for airplanes, helicopters, gliders and multi-rotors
Digital trims with variable step settings
Adjustable stick length and tension
Changeable switch/VR position and AUX channel function
Throttle position warning
Backlit 128x64 DOT LCD screen with adjustable display contrast
Software updateable through the CIU-2
Screen Lock
Earphone/S.Bus/Trainer jacks
Assignable switches (three 3-position, one 2-position)
Range Check
Program navigation bay with jog dial, +/- pads and end pad
Data reset
Model copy
Selectable model type
Fail Safe
End Points
Trim/Trim Resets/Trim Steps
Sub Trim
Servo Reversing
Parameter functions
Servo monitor/Test
Wireless model data transfer
Timer-System and Model (Up/Down)
Trainer system
Airplane Functions
Wing Type (5-wing, 2-tail)
Throttle Cut
Dual Rate/Expo
Throttle Curve
Idle down
Gyro
Aileron differential
V-Tail
Camber
Air Brake
Elevator-to-Flap mixing
Flap-to-Elevator mixing
Elevon mixing
Glider Functions
Wing Type (5-Wing, 2-Tail)
Condition select
Dual Rate/Expo
Motor switch
Gyro
Aileron Differential
V-tail
Butterfly mixing
Trim mixing
Elevator-to-Camber mixing
Camber mixing
Aileron-to-Camber mixing
Helicopter Functions
Swash type (6)
Condition Select
Throttle Cut
Dual Rate/Expo
Trim Offset
Delay
Gyro mixing
Swash AFR
Swash mixing
Throttle Curve (5-point)
Pitch Curve (5-point)
Pitch-to-Rudder mixing
Throttle Hold
Hovering throttle
Hovering pitch
Multicopter Functions
Flight Mode
Center alarm
Dual Rate/Expo
Throttle Curve
Throttle Delay
Gyro
Receiver Specifications:
R3006SB 2.4GHz T-FHSS S.Bus
Type: Full-range flight receiver
Modes: S-FHSS or T-FHSS
Features: bi-directional communication with a T-FHSS transmitter to utilize an array of telemetry sensors, S.Bus and S.Bus2 ports, along with 6 standard PWM outputs
Voltage Input: 4.8V-7.4V
Dimensions: 1.7 x 0.98 x 0.35 in (43 x 25 x 8.8 mm)
Weight: 0.3 oz (8.5 g)
Stock #: FUTL7683
English User Manual,
Package Included:
1 x Futaba T6K 6ch 2.4GHz Transmitter
1 x Futaba R3006CB 6ch 2.4GHz T-FHSS S.Bus Receiver
1 x On/Off Switch Harness, FUTM4385
1 x English Manual
