FuriousFPV PIKO F4 32KHz 16MB Black Box Flight Controller Built-in BEC PDB LED Driver













Description:

Designed as a stackable unit with the feature packed INNOVA V4, the PikoF4 pushes the envelope of performance with
F4 processing power that provides "on the rails" flight capability, augmented by an MPU6000 sensor package with ultra high
8kHz sampling rates. Furthermore, adding a massive 100A maximum built in PDB, the PikoF4 is designed for the extremes
of ultimate FPV.
Featuring 16MB of Black Box flash memory for critical flight data breakdown, the PikoF4 is as cutting edge as it comes,
featuring a built-in inverter for Smartport connection directly to the FC. Offering rich and brilliant feature when it comes to data
feedback for optimal tuning & setup functionality, the PikoF4 is the tuners’ dream for on demand in-flight feedback.
Integrated with an Inrush Voltage Protection system (Input & Output) via Transient Voltage Suppressor, the PikoF4 is wickedly
technical & ready for anything. Add a built in driver inverter for S-bus & integrated buzzer driver with a 5V 1.5A integrated BEC,
the PikoF4 is the all-in-one FC solution that provides everything your quad needs in an ultra simplified design.

Specification:
Item name: Furious FPV PikoF4 flight controller
Size: 27x27mm
Mounting hole: 20x20mm
Screws: M2 with dampers, M3 without dampers
Weight: 3.6g
Voltage Input: 2S 7.4V-6S 22.2V LiPo Power
PDB: 100A Maximum
Processor: F4 Chip
Sensor: MPU6000
BEC: 5V 1.5A

Features:
- F4 Processing Power
- Built In 100A Maximum PDB
- MPU6000 6 Axis Sensor Technology
- 16MB Black Box Flash Memory
- Integrated with an LED Driver for WS2812b Programmable LED's
- Integrated Buzzer Driver
- Built In Driver Inverter for S-bus Capability
- Integrated 5V 1A BEC w/ 2S 7.4V - 6S 22.2V LiPo Power
- Inrush Voltage Protection Input / Output via Transient Voltage Suppressor
- Stackable w/ INNOVA V4
- Stackable ESC 4in1 10A

Package included:
1* Furious FPV PikoF4 flight controller
