FuriousFPV FORTINI F4 32Khz 16MB Black Box Flight Controller Built-in BEC Inrush Voltage Protection
Description:
Description:
With a new high performance, the Fortini F4 has low noise 32kHz Invensense 20602 gyro that features ultra high sensitivity,
this FC is designed for outright performance, offering ultra crisp flight characteristics that will be felt in every move you make.
this FC is designed for outright performance, offering ultra crisp flight characteristics that will be felt in every move you make.
With a massive array of (5) UARTS, the Fortini allows simultaneous connection of SBUS, S.PORT, OSD, USB and either a TBS
Smart Audio System or Immersion RC Tramp. Furthering this, the Fortini is the very first flight controller that offers built in input &
output Inrush Voltage Protection to protect the BEC and other electronic components in the case of extreme voltage spikes.
Smart Audio System or Immersion RC Tramp. Furthering this, the Fortini is the very first flight controller that offers built in input &
output Inrush Voltage Protection to protect the BEC and other electronic components in the case of extreme voltage spikes.
Soft mounted for the ultimate in vibration protection, the Fortini features 16MB of integrated flash memory, allowing BlackBox
functionality to review all data after your flight. The Fortini is also the very first FC to allow S.PORT direct connection with the receiver
without any aspect of receiver modification.
Specification:
Item name: FutiousFPV FORTINI F4 flight controller
functionality to review all data after your flight. The Fortini is also the very first FC to allow S.PORT direct connection with the receiver
without any aspect of receiver modification.
Specification:
Item name: FutiousFPV FORTINI F4 flight controller
Size: 36x36mm
Mounting hole: 30.5x30.5mm
Weight: 5.5g
Mounting hole: 30.5x30.5mm
Weight: 5.5g
Gyro: Invensense 32kHz 20602 Gyro
UARTS Ports: (5)
BlackBox Flash Memory: 16MB
BEC: 5V 2A 2S 7.4V - 6S 22.2V Input Voltage Range (3.3V - 5V Rx Selectable)
Features:
- High Performance, Low Noise, Ultra Sensitive 32kHz Invensense 20602 Gyro
- Five UARTS for Simultaneous Connections of SBUS, S.PORT, OSD, and USB
- UARTS Connection Options for TBS Smart Audio or Immersion RC Tramp
- 16MB of BlackBox Flash Memory for Instant Data Access & Breakdown
- Integrated Soft Mount Rubber Damping for Maximum FC Functionality
- Inrush Voltage Protection Input & Output via Transient Voltage Suppressor
- High Quality 5V 2A BEC w/ 2S - 6S Voltage Input Range
- Built In Driver Inverter for SBUS and Smart Port Connection
- Separate Power Supply for Gyro w/ LDO for Low Noise & High Accuracy
- 3.3V - 5V Selectable BEC Output for Rx
- Fully Capable to Power Rx via USB Port
- Very clean and easy to connect to 4-in-1 ESC
User manual: Fortini F4
BETAFLIGHT TARGET: Betaflight_3.1.7_FORTINIF4.hex
https://github.com/furiousfpv/betaflight/releases
Package included:
1* FutiousFPV FORTINI F4 flight controller
User manual: Fortini F4
BETAFLIGHT TARGET: Betaflight_3.1.7_FORTINIF4.hex
https://github.com/furiousfpv/betaflight/releases
Package included:
1* FutiousFPV FORTINI F4 flight controller
